Telehandler attachment rental

A telehandler without attachments is a lifting machine. With the right range of attachments it becomes a crane, aerial work platform, excavator, loader and cleaning machine - on the same chassis, on the same working day. The hydraulic quick coupler is not an accessory but system architecture: it defines how many specialised machines a single telehandler can replace in the fleet.

Technical principle

The hydraulic quick coupler sits on the boom head. Two hydraulic cylinders tension a locking profile that engages in the standardised mounting of every compatible attachment. Attachment change without leaving the cab, without tools, in under 60 seconds. Hydraulic connections couple automatically when locking; electrical connectors for weighing or controls do so as well.

CE conformity of the combination: the overlooked legal point

This is the most common compliance error in telehandler operation: it is not only the carrier machine and not only the attachment that must be CE-compliant - but the combination of both. The Machinery Directive 2006/42/EC treats carrier machine and attachment as a complete machine as soon as they work together.

Consequences for the buyer:

• Third-party attachments without manufacturer approval for the specific carrier machine can void the CE conformity of the entire system

• Periodic inspection under Government Regulation No. 378/2001 Coll. covers all attachments used; attachments that are not listed will be rejected

• In the event of damage, the operator is liable if non-approved combinations were used

Luibl supplies only attachments with manufacturer approval for the respective carrier machines and with complete CE documentation for the combination.

Pallet forks - basic equipment

Standard design with fixed fork spacing for Euro pallets (800 x 1,200 mm). Decisive when buying: the residual load capacity after deducting the attachment's own weight. A 4 t fork itself weighs 180 - 320 kg; this weight is deducted from the load chart of the carrier machine.

Variants:

Hydraulic fork positioner: fork spread adjustable continuously from the cab; indispensable for changing pallet formats and industrial applications

Wide forks: for oversized loads such as formwork elements, steel beams, pipe bundles

Side shift: horizontal movement of the load without moving the machine; precise positioning in warehouses and during assembly work

Load hook and winch - the crane function

A load hook with a freely suspended load turns the telehandler into lifting equipment (designated lifting equipment). A winch additionally allows controlled lowering and lifting out of pits or shafts.

Technical requirements for operation:

Load attachment with lifting accessories (chains, round slings) in line with applicable Czech safety rules and CSN EN standards

A freely suspended load must not be travelled with - the machine must be stationary

In addition to the telehandler inspection, winch attachments are subject to a separate inspection in line with applicable Czech safety rules and CSN EN standards

Work basket - MEWP function with 360-degree slewing

A CE-approved work basket to EN 280 turns the telehandler into an aerial work platform. Typical load capacity 200 - 350 kg (1-2 persons + tools). On a roto telehandler, the basket rotates with the superstructure - full 360-degree positioning without repositioning the machine.

Critical legal point: When operating with a personnel basket, the requirements of EN 280 apply in full - including periodic inspection under Government Regulation No. 378/2001 Coll. as a MEWP, operator training to ISO 18878 and operating instructions for lifting persons. The operator should explicitly address this in its risk assessment in line with occupational safety rules (Act No. 309/2006 Coll.).

Bucket - earthmoving and material handling

Tipping bucket (standard): for sand, gravel, soil, construction debris; volume 0.3 - 1.2 m3 depending on the model

High-tip bucket: empties over obstacles and into high containers; dumping height up to 3.5 m above ground

Grab bucket: for lumpy material such as stones, tree stumps, demolition waste; hydraulically closing

Bucket with integrated weighing: for recycling, landfills and bulk material intake with billing-grade accuracy

Concrete skip and mortar container

For concreting on hard-to-reach floor slabs and in shaft structures. Capacity 0.3 - 1.5 m3. Emptied via a slide gate, controlled from the cab or by cable pull. An alternative to a stationary crane for small quantities and frequent changes of position.

Clamp fork and pipe grab

For cylindrical loads: concrete pipes, steel pipes, tree trunks, coils. Clamping jaws close hydraulically; the load hangs in the clamp without lifting accessories. Advantage over a load hook: no slinger required, faster handling, more precise positioning.

Sweeper and snow clearing

Sweeper attachments with a hydraulically driven brush set for site access roads, depots and open areas. Working width 1.5 - 2.5 m. A snow plough blade as the counterpart for winter operation.

Telehandlers with a complete, manufacturer-compliant attachment set achieve 15 - 25 % higher selling prices on the used market than bare machines without accessories. The reason: the buyer takes over a ready-to-use system with documented CE conformity - and does not have to buy attachments separately or check compatibility.

For investment planning this means: attachments represent a value of their own alongside the carrier machine. When sold, they increase the residual value of the overall package disproportionately.

• Machinery Directive 2006/42/EC - CE conformity for the carrier machine and attachment combination; manufacturer approval required

• EN 1459-1:2017 - the load chart must show the attachment weight as a deduction

• Government Regulation No. 378/2001 Coll. - periodic inspection covers all attachments used

• Designated lifting equipment - additional inspection for load hook and winch operation in line with applicable Czech safety rules and CSN EN standards

• EN 280:2013+A1:2015 - applies in full for personnel basket operation

Luibl supplies attachments exclusively with:

• manufacturer approval for the specific carrier machine (in writing)

• CE declaration of conformity for the combination

• operating manual in German

• entry in the log book of the carrier machine

Advice on the optimum attachment configuration based on the application profile, the hydraulic data of the carrier machine and your budget. Packages of carrier machine plus attachments can be offered on request as overall financing.
